Neptune Spinner Support Kit - W10181639

Does your Neptune Sound like a rock tumbler? If so, it is possible one of the three bolts snapped on your spinner support where it bolts to the stainless steel inner tub.



Get started disassembling your stand alone Neptune front load washer. There are a number of videos available to help you... The door boot will have to be removed by peeling it from the door opening and removing the spring cable to detach door boot from the tub cover.



Next, you will want to remove the front shroud by removing the (6) screws.

Once the shroud is removed you can remove the tub cover by pulling the (12) clips around the outside of the tub cover. Once the tub cover is off you will want to remove the rear access plate and pop the belt off. Then remove the pulley via 9/16” socket and rock the pulley and it should come off.



Put the washer and 9/16” bolt back in and snug it down to protect the shaft end when you take a 10# hammer to it to convince the tub/spinner to come out the front of machine.



The spinner supports are only available as pre-owned now because they

have been discontinued. Click on the Ebay button to see what is available...

W10181639 Spinner Support

If your Neptune has a timer knob then see www.neptunehelp.com  to see if you have the faulty door latch wax motor
